Nontrivial application in container

FreeIPA experience

Jan Pazdziora

Senior Principal Software Engineer
Identity Management Engineering, Red Hat

13^th May 2015

This work is licensed under a Creative Commons Attribution-ShareAlike 4.0 International License.

This text is also available as slides in PDF format.

Container quickstart

Dockerfile:

FROM fedora
RUN yum -y install httpd && yum clean all
RUN echo "Test Server" > /var/www/html/index.html
CMD [ "/usr/sbin/httpd", "-DFOREGROUND" ]

Build image:

host$ docker build -t httpd .
Sending build context to Docker daemon
Step 0 : FROM fedora
[...]
Successfully built 4b46d7c43d40

Run new container based on the image and talk to it:

host$ docker run --name httpd-c httpd &

host$ docker inspect -f '{{ .NetworkSettings.IPAddress }}' httpd-c
172.17.0.3
host$ curl http://172.17.0.3/
Test Server

Technologies involved

Namespaces
- Mount (filesystems hierarchy)
- Network (devices, IP addresses, routing)
- Process IDs
- User and group IDs (currently not used by Docker)
- UTS (hostname, domainname)
- IPC (SysV IPC, message queues)
Control groups (cgroups) — setting limits
SELinux (use --selinux-enabled with Docker daemon)
iptables (use --icc=false with Docker daemon)

Namespacing examples

PID namespace:

host$ docker exec httpd-c ps ax
  PID TTY      STAT   TIME COMMAND
    1 ?        Ss     0:00 /usr/sbin/httpd -DFOREGROUND
   12 ?        S      0:00 /usr/sbin/httpd -DFOREGROUND
   13 ?        S      0:00 /usr/sbin/httpd -DFOREGROUND
   14 ?        S      0:00 /usr/sbin/httpd -DFOREGROUND
   15 ?        S      0:00 /usr/sbin/httpd -DFOREGROUND
   50 ?        Rs     0:00 ps ax

Network namespace:

host$ docker run fedora tail -n +2 /proc/net/route
eth0    00000000    012A11AC 0003  0      0   0      000000000   0      0
eth0    000011AC    00000000 0001  0      0   0      0000FFFF0   0      0

View namespace transitions on the host:

host# pstree -S | grep docker
        |-docker(mnt)-+-httpd(ipc,mnt,net,pid,uts)---4*[httpd]
        |             `-12*[{docker}]

Filesystems and volumes

The image is mounted as root:

host$ docker exec httpd-c mount | head -1
/dev/mapper/docker-252:17-8193-600d0ac578e0b955c25632be5398921c2ee1e1d6
288b7c687335488f99cb4c28 on / type ext4 (rw,relatime,context="system_u:
object_r:svirt_sandbox_file_t:s0:c264,c680",discard,stripe=16,data=orde
red)

Bind-mounting volume:

host$ mkdir /tmp/data
host$ echo "Test serving data from volume" > /tmp/data/index.html
host$ docker run --name httpd-c -v /tmp/data:/var/www/html:Z httpd &
host$ docker inspect --format '{{ .HostConfig.Binds }}' httpd-c
[/tmp/data:/var/www/html:Z]
host$ ls -aZ /tmp/data | cut -d ' ' -f 1,4,5
drwxr-xr-x. system_u:object_r:svirt_sandbox_file_t:s0:c206,c497 .
drwxrwxrwt. system_u:object_r:tmp_t:s0       ..
-rw-r--r--. system_u:object_r:svirt_sandbox_file_t:s0:c206,c497 index.html

host$ curl http://172.17.0.8/
Test serving data from volume

Approach to containerization

Typical advice when moving application to a container:
- One daemon/service per component.
- Containers can run with their own network and UTS namespaces — they can act as separate machines.
- Use docker run --link to connect them together.
- Bind-mount volumes with configuration/data into directories where programs expect them.
- Install and configure in build time.
- In run time, just start the daemon.

Typical setup

Container: one service		← link	Container: one service	← link		Container: one service
↑ ↖ bind mounts					↗ bind mount
volume	volume				volume
host

Nontrivial application

Running one daemon like httpd above is easy.
- Especially when it does not require any runtime-specific configuration.
- And it does not store state and can be stopped at any moment.
How about application which consists of a dozen of daemons?
Application which needs to do heavy initialization upon the first run.
Individual components use their own paths for configuration and data.
Their startup needs to be synchronized.
There is common configuration tool which assumes everything is on single machine.
FreeIPA is such an application — umbrella on top of multiple services.

Containerizing nontrivial application

If components do not know how to communicate across network, separating them into individual containers might not be feasible.
- Perhaps Unix sockets are used.
- Or the installer simply assumes everything is on localhost.
- Security, authentication.
Locations of files that the programs work with might be hardcoded.
- For OS-level tools, they are often standardized.
- For some, not really documented.
- Bind-mounting dozens of directories increases chance of mismatch.
Components might only be able to finalize their setup in runtime.
Startup and shutdown procedures were polished to perfection by maintainers for individual distributions over the years.

In case of FreeIPA ...

Configuration tools like ipa-server-install or ipa-replica-install are major part of the whole benefit of the project.
- We want to use them, not duplicate their logic.
- They assume all parts are local.
- Only when domain and realm are known once container is run, LDAP, Kerberos, DNS, or CA can be properly set up.
Large number of various directories and files, all over the filesystem.
FreeIPA uses native init system and systemd unit files for service start/stop.

The data and configuration

To minimize number of volumes that will need to be bind-mounted, all data directories and files live under /data.
- In build time, install software with yum install freeipa-server.
- Then move directories and files that will hold instance config and data (and thus define it) to /data-template.
- And create symlinks from original locations to paths under /data.
- Container is run with docker run -v /opt/ipa-data:/data ...
- Upon the first run when empty /data is detected, copy over the vanilla content from /data-template to /data, populating the volume.
- Used docker diff during the work to verify that no unexpected changes get written to the image.
Eventually, we might want to put at least logs to separate volume.

FreeIPA setup

Single container
389	KDC	DNS server	D-Bus	PKI/CA	HTTP Server	SSSD	...
Single image with symlinks to →								`/data`
								↑	bind mount
								volume
host

Using the native configuration tool

The process run as PID 1 is a bash script which detects initial (setup) run vs. routine startup.
For initial, ipa-server-install is run.
- The configuration and data get stored into the volume, via symlinks.
- We had to cheat a bit in some cases — for example keytab files have to be created in image and copied over afterwords.
- The setup tool uses systemctl heavily but there is no systemd running — systemctl replacement scripted to start services directly, while observing systemd unit files.
  - Only supporting syntaxes used by our services.
  - We might want to use native systemd once it runs in Docker containers seamlessly.
For subsequent startup, it just starts the enabled services.

Initial instance configuration

  PID TTY      STAT   TIME COMMAND
    1 ?        Ss     0:00 /bin/bash /usr/sbin/ipa-server-configure-first
   43 ?        S      0:00 xargs /usr/sbin/ipa-server-install -U
   44 ?        S      0:01  \_ /usr/bin/python2 -E /usr/sbin/ipa-server-install -U --ds-password=Secret12345 --admin-password=Secret12345 -r EXAMPLE.COM --setup-dns --forwarder=192.168.100.1
   74 ?        S      0:00      \_ /usr/bin/perl /usr/sbin/setup-ds.pl --silent --logfile - -f /tmp/tmpPjmUla
   89 ?        S      0:00          \_ sh -c /var/lib/dirsrv/scripts-EXAMPLE-COM/ldif2db -n userRoot -i '/var/lib/dirsrv/boot.ldif' 2>&1
   90 ?        S      0:00              \_ /bin/sh /var/lib/dirsrv/scripts-EXAMPLE-COM/ldif2db -n userRoot -i /var/lib/dirsrv/boot.ldif
   91 ?        S      0:00                  \_ /bin/sh ./ldif2db -n userRoot -i /var/lib/dirsrv/boot.ldif -Z EXAMPLE-COM
  119 ?        Sl     0:00                      \_ /usr/sbin/ns-slapd ldif2db -D /etc/dirsrv/slapd-EXAMPLE-COM -n userroot -i /var/lib/dirsrv/boot.ldif
   66 ?        Ss     0:00 /usr/sbin/ntpd -u ntp:ntp -g -x

FreeIPA container running

  PID TTY      STAT   TIME COMMAND
    1 ?        Ss     0:00 /bin/bash /usr/sbin/ipa-server-configure-first
 1470 ?        Ss     0:00 /bin/dbus-daemon --system --fork
 1479 ?        Ss     0:00 /usr/sbin/certmonger -S -p /var/run/certmonger.pid -n
 2010 ?        Ss     0:00 /usr/sbin/kadmind -P /var/run/kadmind.pid
 2020 ?        Ssl    0:00 /usr/bin/memcached -d -s /var/run/ipa_memcached/ipa_memcached -u apache -m 64 -c 1024 -P /var/run/ipa_memcached/ipa_memcached.pid
 2043 ?        Ss     0:00 /usr/bin/perl /bin/systemctl-socket-daemon /var/run/krb5kdc/DEFAULT.socket 0600 ipa-otpd@.service
 2225 ?        Sl     0:01 /usr/sbin/ns-slapd -D /etc/dirsrv/slapd-EXAMPLE-COM -i /var/run/dirsrv/slapd-EXAMPLE-COM.pid -w /var/run/dirsrv/slapd-EXAMPLE-COM.startpid
 2274 ?        Ss     0:00 /usr/sbin/krb5kdc -P /var/run/krb5kdc.pid
 2502 ?        Ss     0:00 sh -c export TOMCAT_CFG_LOADED="1"; export TOMCATS_BASE="/var/lib/tomcats/"; export JAVA_HOME="/usr/lib/jvm/jre"; export CATALINA_HOME="/usr/share/tomcat"; export CATALINA_TMPDIR="/var/cache/tomcat/temp"; export SECURITY_MANAGER="false"; export CATALINA_BASE="/var/lib/pki/pki-tomcat"; export CATALINA_TMPDIR=/var/lib/pki/pki-tomcat/temp; export JAVA_OPTS="-DRESTEASY_LIB=/usr/share/java/resteasy"; export TOMCAT_USER="pkiuser"; export SECURITY_MANAGER="true"; export CATALINA_PID="/var/run/pki/tomcat/pki-tomcat.pid"; export TOMCAT_LOG="/var/log/pki/pki-tomcat/tomcat-initd.log"; export PKI_VERSION=10.2.1; export TOMCAT7_USER="pkiuser"; export TOMCAT7_SECURITY="true"; export NSS_ENABLE_PKIX_VERIFY=1; export NAME=pki-tomcat; /usr/sbin/runuser -g pkiuser -u pkiuser -- /usr/libexec/tomcat/server start
 2503 ?        S      0:00  \_ /usr/sbin/runuser -g pkiuser -u pkiuser -- /usr/libexec/tomcat/server start
 2504 ?        Sl     0:11      \_ /usr/lib/jvm/jre/bin/java -DRESTEASY_LIB=/usr/share/java/resteasy -classpath /usr/share/tomcat/bin/bootstrap.jar:/usr/share/tomcat/bin/tomcat-juli.jar:/usr/lib/java/commons-daemon.jar -Dcatalina.base=/var/lib/pki/pki-tomcat -Dcatalina.home=/usr/share/tomcat -Djava.endorsed.dirs= -Djava.io.tmpdir=/var/lib/pki/pki-tomcat/temp -Djava.util.logging.config.file=/var/lib/pki/pki-tomcat/conf/logging.properties -Djava.util.logging.manager=org.apache.juli.ClassLoaderLogManager -Djava.security.manager -Djava.security.policy==/var/lib/pki/pki-tomcat/conf/catalina.policy org.apache.catalina.startup.Bootstrap start
 2635 ?        Ssl    0:00 /usr/sbin/named-pkcs11 -u named
 2645 ?        Ss     0:00 sh -c export LANG=C; /usr/sbin/httpd $OPTIONS -DFOREGROUND
 2646 ?        S      0:00  \_ /usr/sbin/httpd -DFOREGROUND
 2647 ?        S      0:00      \_ /usr/libexec/nss_pcache 458756 off /etc/httpd/alias
 2648 ?        Sl     0:01      \_ /usr/sbin/httpd -DFOREGROUND
 2649 ?        Sl     0:01      \_ /usr/sbin/httpd -DFOREGROUND
 2650 ?        S      0:00      \_ /usr/sbin/httpd -DFOREGROUND
 2651 ?        S      0:00      \_ /usr/sbin/httpd -DFOREGROUND
 2652 ?        S      0:00      \_ /usr/sbin/httpd -DFOREGROUND
 2653 ?        S      0:00      \_ /usr/sbin/httpd -DFOREGROUND
 2654 ?        S      0:00      \_ /usr/sbin/httpd -DFOREGROUND
 2685 ?        S      0:00      \_ /usr/sbin/httpd -DFOREGROUND
 2733 ?        Ss     0:00 /usr/sbin/sssd -D -f
 2738 ?        S      0:00  \_ /usr/libexec/sssd/sssd_be --domain example.com --uid 0 --gid 0 --debug-to-files
 2740 ?        S      0:00  \_ /usr/libexec/sssd/sssd_nss --uid 0 --gid 0 --debug-to-files
 2741 ?        S      0:00  \_ /usr/libexec/sssd/sssd_sudo --uid 0 --gid 0 --debug-to-files
 2742 ?        S      0:00  \_ /usr/libexec/sssd/sssd_pam --uid 0 --gid 0 --debug-to-files
 2743 ?        S      0:00  \_ /usr/libexec/sssd/sssd_pac --uid 0 --gid 0 --debug-to-files

Publicly accessible server

FreeIPA server provides multiple services on multiple ports

EXPOSE 53/udp 53 80 443 389 636 88 464 88/udp 464/udp 123/udp 7389 9443 9444 9445

Even if bridge networking is used, it is possible to use -p options to docker run to map ports on host's public interface to the container.
But our server is also DNS server and it has record about itself that clients wil query.
From within container, we have no way to find out host's IP address.
Solution: be explicit, host's prefered IP address will be passed in explicitly via environment variable.

The `resolv.conf` and localhost

With FreeIPA, DNS server (bind) can be run in the container.
We rewrite nameserver in container's /etc/resolv.conf to point to 127.0.0.1.
What if we wanted to use DNS server on host's localhost?
No good answer — use either bridge address or host's public IP address.

NTP in container

FreeIPA can setup and run NTP, Kerberos loves time to be in sync.
By default, processes in container do not have capabilities to set time.
Use --cap-add=SYS_TIME to add the capability back.
AVC denial.
Custom SELinux policy needed to allow sys_time capability to svirt_lxc_net_t.

How upgrades work?

	Container
	Image (Built using `yum install`)	Volume (Bind-mounted in runtime)
	Host

Build new image (with yum install).
Remove the old container and run a new one:

	New container
	New image (Built using `yum install`)	Original volume content (Bind-mounted in runtime)
	Host

Upgrades

Upgrade (postinstall) scriptlets in rpms never kick in.
The script which handles initial population needs to detect and handle upgrade situation as well.
- If standalone upgrade process is available in the project, use it.
- Parsing and running the rpm scriptlets also works.
- It helps if the existing mechanisms are idempotent.
Generate /etc/build-id to easily detect different image.
Make sure /data has all the locations that symlinks in the new image expect to exist.

Conclusion

Running multiple services in one container is possible.
Maximize number of steps done in build time.
If your init works in container use it, otherwise work around it.
Minimize number of volumes that the user has to deal with.

References

https://github.com/adelton/docker-freeipa
https://www.freeipa.org/

Nontrivial application in container

FreeIPA experience

Jan Pazdziora

Container quickstart

Technologies involved

Namespacing examples

Filesystems and volumes

Approach to containerization

Typical setup

Nontrivial application

Containerizing nontrivial application

In case of FreeIPA ...

The data and configuration

FreeIPA setup

Using the native configuration tool

Initial instance configuration

FreeIPA container running

Publicly accessible server

The resolv.conf and localhost

NTP in container

How upgrades work?

Upgrades

Conclusion

References

The `resolv.conf` and localhost
