External authentication for Django projects

Jan Pazdziora

Senior Principal Software Engineer
Identity Management Engineering, Red Hat

EuroPython24^th July 2015

This work is licensed under a Creative Commons Attribution-ShareAlike 4.0 International License.

This text is also available as slides in PDF format.

Situation

You've developed successful application using Django.
It makes use of users, presumably based on django.contrib.auth.
Now a large organization plans to deploy the application.
- All its employees should have access.
- Plus associates of its partners and suppliers are to use it.
Desired workflow:
- New person joins the organization.
- They can immediatelly start using the application.
- Preferrably using single sign-on (SSO).
- Authorization derived from group membership in the central system.

Problem statement

Large organizations have existing identity management solutions.
- FreeIPA/IdM, Active Directory, LDAP servers, ...
- With user groups used for access control.
Admins will not create nor manage users in the application manually.
Organizations use standard authentication mechanisms and setups:
- Kerberos / GSSAPI
- Access cards / X.509 / SSL client authentication
- SAML
Organizations often mandate that authentication is done in their verified frontend setup.

Simple setup

Assume the application uses django.contrib.auth.
With django.contrib.auth.views.login and some custom template.

Authentication in frontend HTTP server

We will look at Apache with mod_wsgi but the story is generic.
AuthType set up in Apache configuration.
It sets REMOTE_USER.

Easy answer:

MIDDLEWARE_CLASSES = [
    ...
    'django.contrib.auth.middleware.AuthenticationMiddleware',
    'django.contrib.auth.middleware.RemoteUserMiddleware',
    ...
]
AUTHENTICATION_BACKENDS = [
    'django.contrib.auth.backends.RemoteUserBackend',
]

Or is it?

Limits of `RemoteUserMiddleware`

It assumes external (Apache) authentication covers all locations/URLs that are to be seen as authenticated by the application.
- Apache would need to authenticate every request.
  - Or maintain authentication-related sessions.
- You do not want to renegotiate Kerberos upon every HTTP request.
- We need Apache authentication on /login URL(s) only.
The django.contrib.auth.views.login does not understand when RemoteUserMiddleware has already authenticated the user.
- It will still show the login form.
- Even if the user is authenticated for the request.

Authentication on single URL

Externally-authenticated login URL should initiate authenticated Django session.

<Location /login/>
  AuthType GSSAPI
  AuthName "Kerberos Login"
  GssapiCredStore keytab:/etc/http.keytab
  # GssapiLocalName on
  # Require valid-user
  Require pam-account fin-app-prod
</Location>

<Location /login/>
  SSLVerifyClient require
</Location>

<Location /login/>
  MellonEnable "auth"
</Location>

This way it is easier to fall back to the application-provided login mechanism if needed, making the external authentication optional.

Make it persistent

New PersistentRemoteUserMiddleware in Django 1.9.

A drop-in replacement for RemoteUserMiddleware:

MIDDLEWARE_CLASSES = [
    ...
    'django.contrib.auth.middleware.AuthenticationMiddleware',
    'django.contrib.auth.middleware.PersistentRemoteUserMiddleware',
    ...
]

It keeps the user authenticated.

External authentication aware `login`

Wrap django.contrib.auth.views.login with code actively checking request.user.is_authenticated():

from django.contrib.auth.views import login as auth_login
# additional imports

def login(request, template_name='activity/login.html',
        redirect_field_name=REDIRECT_FIELD_NAME):
    if hasattr(request, 'user') and request.user.is_authenticated():
        redirect_to = request.POST.get(redirect_field_name,
            request.GET.get(redirect_field_name, ''))
        if not is_safe_url(url=redirect_to, host=request.get_host()):
            redirect_to = resolve_url(settings.LOGIN_REDIRECT_URL)
        return HttpResponseRedirect(redirect_to)
    return auth_login(request, template_name = template_name,
        redirect_field_name = redirect_field_name)

Have you got idea for better solution?
- Chime in in https://code.djangoproject.com/ticket/25164.

Additional user attributes

With external authentication, traditionally only the login name is used, provided in REMOTE_USER.
Modern Web applications want to send emails to their users.
Using "<username>@<application's domain>" often does not work.
Modern Web applications would like to make the UI nice by knowing user's name.
And other attributes.
Let's introduce REMOTE_USER_<attribute> variables.

Populating `REMOTE_USER_<attribute>`

For SSSD-based installations, mod_lookup_identity can be used:

<Location /login/>
  LookupUserAttr mail REMOTE_USER_EMAIL
  LookupUserAttr givenname REMOTE_USER_FIRSTNAME
  LookupUserAttr sn REMOTE_USER_LASTNAME
</Location>

Note: remapping in ldap_user_extra_attrs could also be used.

For SAML, the mod_auth_mellon module can populate the attributes from <saml:AttributeStatement>:

<Location /login/>
  MellonSetEnvNoPrefix REMOTE_USER_EMAIL email
  MellonSetEnvNoPrefix REMOTE_USER_FIRSTNAME givenname
  MellonSetEnvNoPrefix REMOTE_USER_LASTNAME surname
</Location>

Consuming attributes in Django

# The real code has a few more checks
class RemoteUserAttrMiddleware(RemoteUserMiddleware):
    def process_request(self, request):
        if hasattr(request, 'user') and request.user.is_authenticated() \
          and user.get_username() == request.META[self.header]:
            stored_backend = load_backend(request.session.get(BACKEND_SESSION_KEY, ''))
            if isinstance(stored_backend, RemoteUserBackend):
                email = request.META.get("REMOTE_USER_EMAIL", None)
                if email is not None:
                    request.user.email = email
                firstname = request.META.get("REMOTE_USER_FIRSTNAME", None)
                if firstname is not None:
                    request.user.first_name = firstname
                lastname = request.META.get("REMOTE_USER_LASTNAME", None)
                if lastname is not None:
                    request.user.last_name = lastname
                request.user.save()

Upon every login, user in Django's auth_user table gets synchronized.

Group-based authorization

Many organizations diligently manage user group membership in their central identity management system.
They want to be able to assign application-level permissions to groups.
And have group memberships propagated without manual edits.
Plan:
- Upon user login, propagate their external group membership into Django groups starting with ext: prefix.
- Application admins will create ext:-prefixed groups for groups that are relevant for the application and assign permissions to them.
- Nonprefixed group are available for local group management.

Populating `REMOTE_USER_GROUP_*`

For SSSD-based installations, mod_lookup_identity can be used:

<Location /login/>
  ...
  LookupUserGroupIter REMOTE_USER_GROUP
</Location>

The mod_auth_mellon module can populate attributes from SAML response:

<Location /login/>
  ...
  MellonEnvVarsSetCount On
  MellonEnvVarsIndexStart 1
  MellonSetEnvNoPrefix REMOTE_USER_GROUP groups
</Location>

Example result:

REMOTE_USER_GROUP_N=2
REMOTE_USER_GROUP_1=network-admin-emea
REMOTE_USER_GROUP_2=network-admin-na

Consuming external groups

# extending RemoteUserAttrMiddleware
class RemoteUserAttrMiddleware(RemoteUserMiddleware):
    group_prefix = 'ext:'

    def update_user_groups(self, request):
        user = request.user
        ext_group_count = request.META.get("REMOTE_USER_GROUP_N", None)
        current_groups = {}
        for g in user.groups.filter(name__startswith=self.group_prefix):
            current_groups[g.name] = g
        for i in range(1, int(ext_group_count) + 1):
            if request.META.get("REMOTE_USER_GROUP_" + str(i), None):
                g = self.group_prefix + request.META["REMOTE_USER_GROUP_" + str(i)]
                if current_groups.has_key(g):
                    del current_groups[g]
                else:
                    g_obj = Group.objects.filter(name=g)
                    if g_obj:
                        user.groups.add(g_obj[0])
        for g in current_groups.values():
            user.groups.remove(g.id)
    def process_request(self, request):
        ...
                self.update_user_groups(request)
                request.user.save()

Conclusion

It is possible to support wild combination of authentication methods, by using authentication frontends.
With PersistentRemoteUserMiddleware, isolated login URLs work.
The login methods need to be checked and possibly amended to observe the external authentication.
Merely login name in REMOTE_USER is often not sufficient.
With custom middleware like RemoteUserAttrMiddleware, user attributes and group memberships can stay in sync.
When new associate logs in, they can not just do it via SSO, they will have their account and permissions fully set up, automatically.
No Python code specific to the authentication methods was written.
This is call for comments: do you find the approach useful?

References

http://www.freeipa.org/page/Environment_Variables#Proposed_Additional_Variables
http://www.freeipa.org/page/Web_App_Authentication
https://code.djangoproject.com/ticket/25164
http://www.adelton.com/django/
